DIGITUS Gigabit Ethernet PoE+ Splitter, 802.3at, 24 W Topseller

DN-95205
EAN 4016032423942

Print version
  • Description

    Gigabit Ethernet PoE+ Splitter, 802.3at Output: 5V/2A, 9V/2A, 12V/2A, 24W

    Integrates Power over Ethernet technology to older non PoE network devices

    • Gigabit Ethernet Speed
    • Fanless design ensures a quiet operation
    • Requires no external power supply unit
    • Adjustable output 5V/2A , 9V/2A, 12V/2A
    • Support 5.5mm and 3.5mm power jack

    The DIGITUS PoE Splitter provide data and power via a single Ethernet Cable to devices, which are not supporting Power over Ethernet. Just connect the input of the Splitter to a PoE Switch or a PoE Injector and the output side to a non-PoE network device such as an access point, IP Phone or a Camera to provide Power and Data. The Extender is self powered by PoE, so there is no additional power supply needed. The output voltage can be regulated via a dip switch to 5V , 9V or 12V. So this Splitter expand your network where you wish to place network device where are no power outlets available.

    Technical Details

    • Ethernet Speed: 10/100/1000Mbps Gigabit Half/Full Duplex
    • PoE Standard: IEEE802.3at
    • Input: Power + Data In (RJ45)
    • Output: Data Out (RJ45) , DC Out
    • Plug-and-Play Installation - No configuration necessary
    • Adjustable output 5V/2A , 9V/2A, 12V/2A
    • Splits the 48VDC power over RJ45 Ethernet cable into different DC output
    • Status LED on the device (PoE ready/ PoE in-use)
    • Circuit isolation protection
    • Maximum power output up to 24 watts
    • Support wide input voltage range 34VDC to 57VDC
    • Thermal cut off
    • Operating Temperature: 0 to 40°C
    • Dimensions (L x W x H): 80 x 55 x 23 mm
    • Weight: 80g
    • Colour: black
    • Ethernet speed: Gigabit
    • Industrial usage: no
    • Power output: 24 W
    • PoE standard: IEEE802.3at (PoE+)

    Package content

    • Gigabit PoE Splitter
    • Manual
    • RJ45 Ethernet cable
    • DC power cable
    • {DE mau}: 3,5mm Stromadapter
  • Logistics

    Number
    (pcs)
    Weight
    (kg)
    Depth
    (cm)
    Width
    (cm)
    Height
    (cm)
    cm³
    Packaging Unit Carton30039,0053,5035,0034,0063665,00
    Packaging Unit Inside10,1315,308,002,50306,00
    Packaging Unit Single10,1315,308,002,50306,00
    Net single without Packaging10,1215,308,002,50306,00
  • Downloads

    Manual
