DIGITUS 16 Port Gigabit Ethernet PoE+ Injector, 802.3at, 250 W Topseller

DN-95116
EAN 4016032430377

Print version
  • Description

    Gigabit Ethernet PoE+ Injector Hub, 802.3at, 10G 16-port, Power Pins:3/6(+), 1/2(-), 250W

    Minimization of the cabling costs for PoE-capable devices

    • 16 gigabit ports with PoE+ support
    • 250 watt performance with up to 30 watts per port
    • Compatible with the IEEE802.3af and IEEE802.3at standards
    • Automatic surge protection
    • Supports bandwidth up to 10Gbps

    The DIGITUS® DN-95116 is an 16 port gigabit PoE+ mid-span hub (PoE injector). It offers 16 input ports for data and 16 output ports which make data and PoE available. Each PoE-port supports connected devices in accordance with the IEEE802.3af and IEEE802.3at PoE standard with 15.4 watts and/or 30 watts, such as PoE access points, PoE IP-telephones or PoE IP cameras, for example. The switch makes available a maximum budget of 250 watts for all ports and maximum budget of 30 watts per port.

    Technical Details

    • 32 x 10/100/1000Mbps/2.5G/10G (16 x input data, 16 x output data+PoE)
    • Compatible with the IEEE802.3af and IEEE802.3at standards
    • PoE power supply via PIN 1.2(V-) and PIN 3.6(V+)
    • Maximum total output of 250 watts
    • Compatible with IEEE802.3, IEEE802.3u and IEEE802.3ab standards
    • Automatic cable recognition - Auto-MDI-/ MDI-X function
    • Auto recognition of full and half duplex
    • Power supply: 100V AC ~ 240V AC
    • Operating temperature range: -10 °C to +45 °C
    • Storage temperature: -20°C - 70°C
    • Dimensions (mm): 440(L) x 200(W) x 45(H)
    • MTBF: 100,000 hours
    • Ethernet speed: Gigabit
    • Industrial usage: no
    • Number of ports: 16
    • PoE Power budget: 250 W
    • PoE standard: IEEE802.3af (PoE)

    Package content

    • 16 port gigabit PoE+ injector
    • Quick start guide
    • Power Cord cable
    • Mounting accessories
  • Logistics

    Number
    (pcs)
    Weight
    (kg)
    Depth
    (cm)
    Width
    (cm)
    Height
    (cm)
    cm³
    Packaging Unit Carton520,8359,5029,5022,0038615,50
    Packaging Unit Inside14,1750,0028,0010,0014000,00
    Packaging Unit Single14,1750,0028,0010,0014000,00
    Net single without Packaging14,1250,0028,0010,0014000,00
  • Downloads
